Agriculture Borewell Waterfilled Submersible Pumps by Kirloskar

APPLICATIONS

Horticulture & Agriculture

Domestic and Community Water Supply

Sprinkler and Drip Irrigation

Rural Water Supply

Ground Water Supply to Water Works

SPECIFICATIONS

Head : Up to 427 Metres

Capacity : Up to 650 LPM

Power Rating : 2 .2 to 18.3 kW / 3 to 25 HP

Voltage range : 200 to 440 volts (three phase)

Type of cooling : Water-filled

Insulation : B class

Protection : IP 68

MATERIAL OF CONSTRUCTION

HHN

Impeller: Noryl

Diffuser: Noryl

Diffuser Casing: Cast Iron

Pump Shaft: Stainless Steel

Motor Body: Stainless Steel

Motor Shaft: Stainless Steel

Finished Rotor: Copper

NRV: Cast Iron

Suction: Cast Iron

Pump/Motor Bushes: LTB

Thrust Bearing: Carbon + SS

DOL: Cast Iron

HHF

Impeller: Stainless Steel

Diffuser: Stainless Steel

Diffuser Casing: Stainless Steel

Pump Shaft: Stainless Steel

Motor Body: Stainless Steel

Motor Shaft: Stainless Steel

Finished Rotor: Copper

NRV: Cast Iron

Suction: Cast Iron

Pump/Motor Bushes: LTB

Thrust Bearing: Carbon + SS

DOL: Cast Iron

FEATURES

Wide Voltage Motor Designs with 100% Copper Rotor

Sand Fighter Designs

Dynamically Balanced Rotating Parts

Longer and Trouble Free Life

High Head Applications

CED – Cathode Electro Deposition Coating

Designed to Prevent Overloading

Shielded Ball Bearing
