Borewell Oilfilled Submersible Pumps by Kirloskar

APPLICATIONS

High rise building

Bungalows & Hotels

Agriculture & gardening

Domestic water supply

SPECIFICATIONS

Power Rating - 4.5 to 18.5 kW (6.0 to 25.0 HP)

Voltage Range - 200 to 440 Volts (Three Phase)

Head Range - From 6 Meters to 81 Meters

Discharge Range - From 1850 LPM to 600 LPM

Type of Cooling - Oil Cooled

Insulation - F Class

Protection - IP 68TECHNICAL

MATERIAL OF CONSTRUCTION

Motor Housing - Stainless Steel

Motor Shaft - Stainless Steel

Motor Bearing - Ball Bearing

Finish Rotor - Copper

Motor Base & Adaptor - Cast Iron

Pump Shaft - Stainless Steel

Pump Stage Casing - Cast Iron

Impeller - Stainless Steel

Outlet (NRV) - Cast Iron

Suction Housing - Cast Iron

FEATURES

Innovative enhancements in efficiency and lower power usage

Ideal and appropriate for horizontal performance

Impressive and well-suited for low voltage operations

Incredible design for persistent operation

Indigenous crafting to minimize motor burnout risks

Inexpensive with prolonged durability
