Borewell Pump by kirloskar

APPLICATIONS

Domestic and Community Water Supply

Rural Water Supply

Gardening and Small Farm Irrigation

Construction Site

Water Supplies for High Rise Building

SPECIFICATIONS

Head Range : Up to 276 metres

Discharge Range : Up to 1540 LPM

Power Ratings : 2.2 to 18.5 kW (3 to 25 HP)

Voltage Range : 160 to 240 volts (single phase)

200 to 440 volts (three phase)

Insulation : B class

Type of Cooling : Water-filled

Protection : IP 68

MATERIAL OF CONSTRUCTION

Impeller : Stainless Steel / Noryl

Diffuser : Cast Iron / Noryl

Bowl/Stage casing : Cast Iron

Pump Shaft : Stainless Steel

Motor Housing : Stainless Steel

Motor Shaft : Stainless Steel

Finished Rotor : Copper

NRV : Cast Iron

Suction : Cast Iron

Pump /Motor Bushes : NBR / LTB

Thrust Bearing : Carbon + SS

FEATURES

Wide Voltage Design

High efficiency and Energy Saving Design

Dynamically Balanced Rotating Parts

Longer and Trouble Free Life

Advanced Water-cooled Motor Design

Wide Voltage Motor Design with 100% Copper Rotor

CED – Cathode Electro Deposition Coating
