Monobloc Pumps BY KIRLOSKAR

Applications

Gardening and Small Farm Irrigation

Lawn Sprinklers

Water Supplies for High Rise Building

Domestic and Community Water Supply

Water Transfer and Circulation

SPECIFICATIONS

Head Range: Up to 52 metres

Discharge Range: Up to 28 LPS

Power Ratings: 0.37 to 3.7 kW (0.5 to 5.0 HP)

Voltage Range: 180 to 240 volts (single phase) & 120 to 220 volts (low voltage) & 230 to 400 volts (“P” series)

Insulation: B / F class

Protection: IP 44 / IP 55

MATERIAL OF CONSTRUCTION

Impeller: Cast Iron/Noryl

Delivery Casing: Cast Iron

Motor Body: Cast Iron

Pump Shaft: Carbon Steel

Sealing: Mechanical Seal

FEATURES

Wide Voltage Design

Replaceable Wearing Parts

TOP - Thermal Overload Protector

CED – Cathode Electro Deposition Coating

Automatic Air Release

High Efficiency and Energy Saving Design

Designed to Prevent Overloading

Dynamically Balanced Rotating Parts
