Sewage / Dewatering Submersible Pumps BY KIRLOSKAR
Description
APPLICATIONS
Sewage Pumping
Dewatering from Basements, Multi-storeys, Shopping Malls, Godowns, etc.
Construction Site
Dewatering Foundation, Trenches and Pits
Flood Water Handling
SPECIFICATIONS
Head Range: Up to 70 metres
Discharge Range: Up to 4800 LPM
Power Ratings: 0.75 to 15 kW (1 to 20 HP)
Voltage Range: 380 to 440 volts (three phase)
Insulation: B / E class
Protection: IP 68
pH Value: 6.5 to 7.5
Maximum Ambient: 40° C temperature
Maximum Density: ≤ to 1050 kg/m3
Consistency of Medium: < 1.2 x 103 kg/m3
MATERIAL OF CONSTRUCTION
Impeller: Cast Iron
Delivery Casing: Cast Iron
Motor Body: Cast Iron
Pump Shaft: Carbon Steel
FEATURES
High Efficiency and Energy Saving Design
Easy Maintainable Design
CED – Cathode Electro Deposition Coating
Robust Construction
Replaceable Wearing Parts
Dynamically Balanced Rotating Parts
