Vacuum Pumps By Kirloskar

APPLICATIONS

KBL’s exclusive range of KV/DV vacuum pumps are majorly used for priming of large pumps. As the name suggests, these are also used to create a ‘vacuum’ by enabling evacuation of air and thus are widely used for applications like drying, evaporation, degasification, condensation, etc.

Priming of Large Pumps

Evacuation of Air from Suction Pipes and Chambers

Twist Drilling Machine, Removing Water from Pulp Layer, Labelling, Bottle Filling, De-odorising, etc.

Drying, Evaporation, Distillation, Filtration, Sterilisation, Condensation, Degasification, Sucking Gases, etc.

Extrusion Machines

SPECIFICATIONS

Vacuum: Up to 600 mm of mercury

Air Flow Rate: Up to 55 m/hr (at mean sea level)

Power Ratings: 0.75 to 2.2 kW (1 to 3 HP)

Voltage Range: 180 to 240 volts (single phase) 300 to 440 volts (three phase)

Insulation: B class

Protection: IP 44

MATERIAL OF CONSTRUCTION

Rotor (Impeller) : Stainless Steel

Delivery Casing : Cast Iron

Motor Body : Cast Iron

Pump Shaft : Carbon Steel

FEATURES

Wide Voltage Design

Designed to Prevent Overloading

Replaceable Wearing Parts

Dynamically Balanced Rotating Parts
